swing gate

formation of protective pipes

In the case of a swing gate, the photocell outlet must be moved from the center towards the street (in the opposite direction to the opening). The position of the motor is determined by the mounting point of the lever. It is typically between 400-500mm.

sliding gate

formation of protective pipes

In the case of a sliding or rolling gate, the protective pipe is placed in the concrete base. It is necessary to leave 500 and 300 mm from the outer and inner edges of the column. The basic size of the sliding gate is half the width of the opening. (eg opening 3m, floating gate base 1.5m, total length of floating gate 4.5m)
